Magnetic Stirrer (Stirring Only)
LABWAN High Capacity Magnetic Stirrer with Microprocessor & Brushless Motor LIMS-100L
Model LIMS-100L
In Stock
The High Capacity Magnetic Stirrer features a brushless DC motor for quiet, maintenance-free operation, microprocessor control with variable speed and time settings, last-run memory, selectable acceleration rates, programmable pulse mode, and a stainless-steel setup plate for corrosion protection. It also provides automatic operation after power failure, power overload protection, and long timer settings up to 99 hours 59 minutes with infinite mode.
Get Quote
Catalog Not Available
ISO 9001 Certified
Service & Support
Key Features
- Brushless DC motor for quiet, maintenance-free operation
- Microprocessor controlled
- Variable speed and time setting
- Last-run memory function
- Selectable acceleration rates from A1 to A9
- Programmable pulse with direction change
- Stainless-steel setup plate for corrosion protection
- Automatic power-on after power failure
- Power overload safety feature
- Long timer setting up to 99 hours 59 minutes and infinite mode
- Supplied with stir bar and support frame
Specifications
| Parameter | Value |
|---|---|
| Motor Type | Brushless motor |
| Max. Capacity | 100 Liters |
| Variable Speed | 100 - 800 RPM |
| Run Time | 1-99 hours 59 mins & infinite |
| Ramp Up Speed Feature | User can select different Acceleration rates (A1-A9 with A9 being the fastest rate and A1 slowest) |
| Pulse Mode | Alternating clockwise and anticlockwise motion with adjustable variable time 30-300 sec |
| Digital Display | Yes |
| Accuracy | ± 10 RPM |
| Product & Plate Dimensions (SS) | 393 x 267 x 105 mm & 215 x 294 mm |
| Max. Stir Bar Length | 80 mm |
| Protection Class | IP 21 |
| Structure Frame Size (With adjustable height) | 504 x 500 x 164 mm |
| Weight | 5.5 Kgs |
| Voltage / Consumption | 100-240V AC, 50/60 Hz |
| Accessories | Stir bar, support frame |
